Energy Meter Test Equipment

Energy Meter Testing Equipment

Accurate energy measurement is critical for efficiency, compliance, and reliability. Rigil Geny’s Energy Meter Testing Equipment ensures unmatched precision for single-phase, three-phase, and portable testing solutions, meeting global standards like GB, IEC, CE, and ISO. Designed for manufacturers, utilities, and laboratories, our solutions provide advanced testing capabilities for voltage, current, power, and harmonics. Trust our expertise to enhance accuracy, reduce errors, and optimize performance in energy metering.

Portable Reference Meter

YC98S1 Three Phase Portable Reference Standard Meter

0.05% High Accuracy (direct connection)
With 7 inches 480×234 dot TFT colour screen
Wide voltage supply range: 55V~480V
Connection with current clamp: standard 100A from
5A to 2000A as option
Two ways for power supply: external AC power supply or test lead power supply

YC98S1H Portable Three Phase Standard Meter

5inch high resolution LCD touch screen
USB interface and can save 20000 records (256MB)
Automatic test sequence using the scanning head for electronic and electromechanical meters
Li battery power supply mode (>3 hours) and test circuit power supply mode

YC2000C Portable Single-Phase Standard

Current clamp and meter combined together, colourful and touch-screen display
Wide voltage, current measurement range, 15V-300V, 5mA-100A
Current clamp has automatic compensation function, 0.2% class accuracy, with automatic calibration function
16-bit high accuracy AD switch 32 bits ARM processor core
Automatically record and store 999 group calibrate data
Measure virtual value of alternating Voltage (15~300Vrms) and alternating current (50mA~100Arms)

Power Sources & Calibrators

YC99T-5C Three Phase 3 Positions Portable Calibrator

It comprises of 01 set of test racks, in total of 3 nos. of test stations with accuracy 0.05

Power source: Inbuilt up to 120 Amps
Ref. standard: Inbuilt with 0.05
Test Rack 03 positions
PC operation Software
High Stability

YCSS-101 Single Phase Standard Power Source

Single Phase power source up to 100 amps
Ref. standard: – Class 0.05
Error Calculation System
Suitable to test up to 03 meters
Standard Output Source

YCSS-103 Three Phase Standard Power Source

Three Phase power source up to 100 amps
Ref. standard: – Class 0.05
Suitable to test up to 03 meters
Standard Output Source

Stationary Test Benches

YC1891 Single Phase Meter Test System

Meters under testing: 1P2W all types of single phase meter
Testing mode: active power, reactive power & apparent power
With MSVT, can test single-phase meters with Closed links (I-P links)
With current output switch, current 2-element meters
Installing RS232, Ethernet communication ports in each meter position, to realize automatic calibration of electronic meters

YC1893 Three Phase Meter Test System

Meters under testing: 3P4W, 3P3W, 1P2W
Testing mode: active power, reactive power & cross connected reactive power Installing the ICT in each meter position to test three-phase meter with closed links between the current and voltage measuring circuits (I-P links)
Neutral current test
Installing RS232, Ethernet communication ports in each meter position, to realize automatic calibration of electronic meters
Starting test & creeping test

Automated Calibration & Test Line

Single Phase Automatic Calibration & Testing Line

Buffer Stage
HV/IR
FT (including the RTC/MC/RT)
PH Cal
Neutral Cal
Starting test
Creep Test
Error 1 (Load points for PH)
Error 2 (Load points for N)
Buffer/ Additional Stage
Output Decision Stage
